30 Series vs 40 Series vs 60 Series Push Pull Control Cables: Which Cable Is Right for Your Application?
 "30 Series vs 40 Series vs 60 Series Push Pull Control Cables: Which Cable Is Right for Your Application?")
Selecting the correct push pull control cable is essential to ensuring reliable equipment performance, smooth operation and long service life. Whether you're replacing an existing Morse® or Teleflex® cable or specifying a new mechanical control cable, understanding the differences between the 30 Series, 40 Series and 60 Series cable families will help you choose the right solution for your application.
At Industrial & Cable Group, we supply Australian-assembled push pull control cables, motion control cables and control cable assemblies for customers across agriculture, mining, earthmoving, transport, marine, motorsport and industrial sectors. This guide explains the key differences between each series and provides practical advice on selecting the right cable.
What Is a Push Pull Control Cable?
A push pull control cable is a flexible mechanical device that transmits motion and force from an operator to a remote control point. Unlike standard pull-only cables, push pull cables are engineered to both push and pull, making them ideal for applications such as:
- Engine throttle controls
- Transmission and gear selection
- PTO engagement
- Hydraulic valve operation
- Engine shut-down systems
- Remote mechanical actuators
Also known as mechanical control cables, motion control cables or control cable assemblies, these systems provide a dependable alternative to hydraulic, pneumatic or electronic controls in many industrial applications.
Understanding the Three Main Cable Series
Although the three cable series look similar externally, they are designed for different operating loads and applications.
| Feature | 30 Series | 40 Series | 60 Series |
|---|---|---|---|
| Typical Duty | Light to Medium | Medium to Heavy | Heavy to Extreme |
| Rod Diameter | 3/16" | 1/4" | 5/16" |
| Push/Pull Capacity | Moderate | High | Maximum |
| Typical Equipment | Utility & General Machinery | Earthmoving & Transport | Mining & Heavy Industrial |
| Flexibility | Excellent | Very Good | Heavy Duty |
| Custom Lengths Available | Yes | Yes | Yes |
The correct cable depends on the operating force, installation requirements and environmental conditions.
30 Series Push Pull Control Cables
Best suited for light to medium-duty applications
30 Series push pull control cables are among the most versatile mechanical control cables available. Featuring a 3/16" stainless steel rod, they provide smooth operation and reliable performance across a wide variety of industries.
Common applications include:
- Throttle controls
- Gear selector systems
- PTO engagement
- Engine shut-off controls
- Hydraulic valve operation
- Agricultural machinery
- Marine equipment
- Commercial vehicles
- Waste equipment
- Light industrial machinery
If you're replacing a Morse 30 Series or Teleflex 30 Series cable, this is typically the appropriate replacement.
Best for:
- Agriculture
- Transport
- Light construction equipment
- General industrial machinery
30 Series Push Pull Control Cables
40 Series Push Pull Control Cables
Designed for heavier operating loads
40 Series push pull control cables utilise a larger 1/4" stainless steel rod, providing increased push and pull capability while maintaining excellent control and flexibility.
They are commonly selected where equipment requires greater operating force than a 30 Series cable can provide.
Typical applications include:
- Heavy-duty throttle systems
- Hydraulic valve controls
- Transmission controls
- PTO systems
- Earthmoving machinery
- Construction equipment
- Heavy transport
- Mining equipment
- Concrete agitators
If your equipment experiences high vibration, long operating hours or demanding duty cycles, 40 Series cables are often the preferred solution.
Best for:
- Earthmoving
- Construction
- Mining
- Heavy transport
- Waste management
40 Series Push Pull Control Cables
60 Series Push Pull Control Cables
Maximum strength for severe-duty applications
60 Series push pull control cables are engineered for the highest operating loads and the most demanding industrial environments.
Featuring a 5/16" stainless steel core, they provide superior push and pull performance where heavy mechanical loads must be transmitted over longer cable runs.
Common applications include:
- Large hydraulic valve systems
- Heavy transmission controls
- Industrial processing equipment
- Mining machinery
- Civil construction equipment
- Heavy mobile plant
- Infrastructure equipment
- Rail applications
These cables are designed for applications where reliability is critical and equipment downtime is costly.
Best for:
- Mining
- Heavy earthmoving
- Infrastructure
- Industrial processing
- Heavy mobile plant
60 Series Push Pull Control Cables
How Do I Choose the Right Cable Series?
Choosing the correct push pull cable depends on several important factors:
Operating Load
Higher operating forces generally require a larger cable series.
Cable Travel (Stroke)
The required amount of cable movement must match the equipment's operating requirements.
Cable Routing
Long cable runs or multiple bends may influence the recommended cable series.
Environment
Applications exposed to vibration, dust, mud, water or corrosive environments benefit from heavy-duty cable construction.
Existing Equipment
When replacing an existing cable, matching the original cable series is usually recommended unless operating conditions have changed.
If you're unsure, Industrial & Cable Group can assist by identifying the correct replacement from:
- Existing cable measurements
- Original part numbers
- Equipment make and model
- Customer drawings
- Sample cables
Morse and Teleflex Cable Replacement Solutions
Many Australian machines continue to use original Morse® or Teleflex® cable assemblies.
Industrial & Cable Group manufactures high-quality replacement cables compatible with many legacy systems across the 30, 40 and 60 Series range.
Our replacement cables are available in custom lengths, travel and end fitting configurations, allowing worn, obsolete or discontinued cable assemblies to be replaced quickly and accurately.
Why Choose Industrial & Cable Group?
Industrial & Cable Group supplies Australian-assembled push pull control cables backed by decades of industry experience.
Our customers benefit from:
- Australian assembly
- Premium stainless steel components
- Custom cable lengths
- Custom cable travel (stroke)
- Morse and Teleflex replacement expertise
- Expert technical advice
- Fast Australia-wide delivery
- Online Build-A-Cable configurator
- Extensive range of accessories and end fittings
Whether you require a light-duty 30 Series cable or a maximum-strength 60 Series assembly, our team can help you select the right mechanical control cable for your equipment.
Need Help Choosing the Right Push Pull Cable?
If you're unsure which cable series best suits your application, our experienced team can help.
Contact Industrial & Cable Group for expert advice on selecting the correct push pull control cable, mechanical control cable or custom control cable assembly for your equipment.
